Bavaria 50 Vision

Overview Technical data Fittings & Equipment Optionals Basic packages Images

Overview

Bavaria 50 vision represents the peak of  luxurious and comfortable performance cruisers and offers a highly increased standard in equipment and speed. A new hull design, a ballast ratio of above 35%, and significantly increased sail areas are all part of it.

Overview

Technical data

Length overall 15,70 m
Length hull 14,99 m
Length waterline 13,45 m
Beam overall 4,49 m
Draught standard approx. 1,90 m
Draught option approx. 2,30 m.
Unloaden weight approx. 13.500 kg
Ballast approx. 4.850 kg
Engine Volvo-Penta D2-75, 53 kW/ 72 hp
Water tank approx. 790 l
Fuel tank approx. 320 l
Cabins / Berths 3/6
Mainsail & Genoa approx. 138,00 sqm
Height of mast above waterline approx. 21,65 m
Height in salon approx. 2,14 m

Fittings & Equipment

Exterior

Hull

  • Hull color white
  • 6 hull windows (fixed)

Rudder/Keel

  • Lead/cast iron keel - shallow draft
  • Symmetrical rudder with fore balance
  • Emergency tiller

Steering pedestral

  • Double steering pedestal
  • 2 steering wheels with leather cover

Deck

  • Deck ventilator
  • Side deck and coach roof with anti slip structure
  • 4 aluminum cleats
  • Coaming for sprayhood
  • Pulpit, pushpit
  • Guardrail
  • Bow fitting with anchor roller

Bathing platform

  • Bathing platform electrical lowerable with teak
  • Bathing ladder stainless steel (telescope)
  • Cockpit-shower (cold)

Cockpit

  • Teak on cockpit floor and cockpit seats
  • Cockpit table
  • Box for gas bottles, self drained

Standing/running rigging

  • Mainsail, coordinated for conventional rig
  • Vorsegelrollreffeinrichtung
  • Genoa, coordinated for standard fore sail reefing gear
  • Conventional Sport rig

Winches

  • 2 winch handles
  • 2 halyard winches, self-tailing
  • 2 genoa winches, self-tailing

Interior

Cabins

  • 3 cabins with 6 fixed berths and salon
  • Cabinet in foreship and aft cabin

Bathroom

  • Pump-toilet with holding tank, disposal via seacock and deck suction

Salon

  • Salon table, fixed
  • Salon with settee
  • Upholstery Vision Blue / Vision Beige
  • Sideboards, shelves and cabinets
  • Storage lockers

Navigation area

  • Chart table with console for instruments
  • Chart table seat

Pantry

  • 2-flame gas cooker with oven
  • Icebox with compressor
  • Refrigerator 80 l
  • Stainless steel sink
  • 4 fire extinguisher
  • Fire extinguisher blanket

Miscellaneous

Water supply

  • Fresh water tank with level indicator 400 l
  • Electrical pressurized water pump with filter

Bilge pump

  • Manual bilge pump
  • Electrical bilge pump

Engine

  • Two circuit cooling with seawater filter
  • Engine hour meter and rev meter
  • Voltmeter, Fuel indicator

Electrical system

  • Engine circuit 88 Ah, on board electrical system 135 Ah
  • Main power supply with circuit breaker and control lamps
  • AC-outlet package (1 per cabin and 2 in galley)
  • Shore supply 230 V (1 x 230 V AC-outlet on switch board) (shore supply 110 V for surcharge)
  • 12 V-outlet at switch board

Navigation

  • Windex
  • Navigation lamps, deck light

Optionals

Exterior

Rudder/Keel

  • Lead/Cast iron keel deep draft
  • Bow thruster SE 80, electric (only in combination with 2nd service battery)

Anchor

  • Electrical windlass
  • Plough anchor, zinc-coated
  • Anchor chain, zinc-coated, Ø 10 mm, 50 meters
  • Anchor chain, stainless steel, Ø 10 mm, 50 meters

Deck

  • Sun upholstery for deck
  • Teak on side deck and coach roof
  • Guardrail opening on both sides
  • 2 spring cleats, aluminium, midships
  • 4 stainless steel cleats
  • 2 spring cleats, stainless steel, only in combination with 4 stainless steel cleats
  • Life-saving collar with holding device and life line, installed at pushpit
  • LFS-safety package, life-safety system

Bathing platform

  • Cockpit-shower warm (only in combination with warm water boiler 20 l)

Cockpit

  • Sprayhood
  • Bimini (deck rigging)
  • Bimini, large (rigging on pushpit)
  • Camper cover
  • Upholstery on seat thwarts in cockpit

Standing/running rigging

  • Fully battened mainsail with MDS-system and lazyjacks, reefing genoa
  • High-tech sailset for mainsail-furling system; furling main, EMS-System, sandwich laminate, reefing genoa with e-foam, tri-radial, cut and surface optimized.
  • High-tech sailset for battened main and genoa, cut and surface optimized, sandwich/laminate cloth; battened main incl. MDS & lazyjacks, bi-radial; reefing genoa with e-foam, tri-radial.
  • Backstay adjuster with handel
  • Spinnaker gear complete with spinnaker boom and holding device; Downhaul with separate chain plate, excenter cleats for halyard and topping lift, topper for downhauls, leading blocks at mast and rail stanchions, leading blocks, spi-lift system.
  • Rodkick with gas pressurized spring
  • Gennaker boom
  • Mainsail furling system

Winches

  • Spi-winches, 2-gear, self-tailing
  • 1 genoa reefing winch, 2-gear, self tailing
  • 2 x Electric genoa winches
  • 2 x Larger genoa winches
  • 2 x Larger halyard winches

Interior

Head

  • Shower in fore head
  • Shower in aft head with shower room separation

Pantry

  • 3-flame gas cooker with oven

Miscellaneous

  • Steel cradle for oversea transport
  • Life raft (in bag)
  • First aid kit "Coastal"
  • Hot air heating, 3,5 KW, fuelling via engine fuel tank

Water supply

  • Additional water tank in foreship 390 l
  • Warm water boiler 20l  via engine-cooling circuit and via 230 V shore supply

Engine (additional charge to basic engine)

  • Folding propeller, 4-blade (only in connection with Volvo-Penta D2-75)

Electrical system

  • Diesel generator, 4,5 kVA
  • 2nd additional battery 135 Ah
  • Shore supply 110 V (1x 110 V AC-outlet on switch board)
  • Battery charger, 45 A (3-channel)

Multimedia

  • TV 19" in Salon with DVD
  • TV-cabling, incl. antenna with outlets
  • Radio with CD-/MP3-Player with 2 speakers in salon

Navigation

  • VHF-cabling, incl. antenna, installed in mast to chart table
  • Raymarine Tridata ST 60 Plus (log, echo sounder and temp), per unit
  • Autopilot, Raymarine ST 6002
  • Electr. wind gauge, Raymarine
  • Chart plotter, Raymarine C 80 with GPS (cockpittable)
  • Chart plotter, Raymarine E 80 with GPS, for chart table, only

Basic packages

Performance

  • Larger genoa winches
  • Larger halyard winches
  • Rodkick with gas pressurized spring
  • High-tech sailset for battened main and genoa,  sandwich/laminate cloth; battened main incl. MDS & lazyjacks, bi-radial; reefing genoa tri-radial
  • Backstay adjuster, tackle
  • Spinnaker gear complete with spinnaker boom and holding device; Downhaul with separate chain plate, excenter cleats for halyard and topping lift, stopper for downhauls, leading blocks at mast and rail stanchions, leading blocks, spi-lift system
  • Gennaker boom
  • Raymarine Tridata ST 60 Plus (log, echo sounder and temp)
  • Folding propeller, 4-blade (only in connection with D2-75)

Family

  • 2 spring cleats, aluminium, midships
  • Sprayhood
  • Bimini (deck rigging)
  • Rodkick with gas pressurized spring
  • Mainsail-furling system
  • Battery charger, 45 A (3-channel)
  • 2nd additional battery, 135 Ah
  • Warm water boiler 20l via engine-cooling circuit and via 230V shore supply
  • Raymarine Tridata ST 60 Plus (log, echo sounder and temp)

Family - north (Equipment analog to Family)

  • without sprayhood and bimini

Holiday

  • 2 spring cleats, aluminium, midships
  • Sprayhood
  • Bimini (deck rigging)
  • Rodkick with gas pressurized spring
  • Battery charger, 45 A
  • VHF-cabling, incl. antenna, installed in mast to chart table
  • Shower in fore head
  • Shower in aft head with shower room separation
  • Warm water boiler 20l via engine-cooling circuit and via 230V shore supply
  • Raymarine Tridata ST 60 Plus (log, echo sounder and temp)
  • Auto pilot, Raymarine ST 6002
  • Electr. wind gauge, Raymarine

Comfort

  • Teak on side deck and coach roof
  • Rail opening on both sides
  • 4 stainless steel cleats
  • 2 stainless spring cleats
  • Sprayhood
  • Bimini (deck rigging)
  • Rodkick with gas pressurized spring
  • Mainsail-furling system
  • Battery charger, 45 A (3-channel)
  • 2nd additional battery, 135 Ah
  • Warm water boiler 20l via engine-cooling circuit and via 230V shore supply
  • Raymarine Tridata ST 60 Plus (log, echo sounder and temp)
  • Electr. wind gauge, Raymarine

Function package (bundle)

Ancoring

  • Electrical anchor winch
  • Plough anchor, zinc-coated
  • Anchor chain, zinc-coated, Ø 10 mm, 50 meters

Multimedia

  • TV 19" in salon with DVD
  • TV cabling incl. antenna and AC-outlets
  • Radio with CD-/MP3-Player with 2 speakers in salon

Safety

  • Life-saving collar with holding device and life line, installed at pushpit
  • LFS-safety package, life-safety system
  • Life raft (in bag)
  • First aid kit coastal

Navigation I

  • VHF-cabling, incl. antenna, installed in mast to chart table
  • Raymarine Tridata ST 60 Plus (log, echo sounder and temp)
  • Auto pilot, Raymarine ST 6002
  • Electr. wind gauge, Raymarine

Navigation II

  • VHF-cabling, incl. antenna, installed in mast to chart table
  • Raymarine Tridata ST 60 Plus (log, echo sounder and temp)
  • Auto pilot, Raymarine ST 6002
  • Electr. wind gauge, Raymarine
  • Chart plotter, Raymarine C 80 with GPS (chart table)
