Bavaria 34 Cruiser

The new Bavaria 34 cruiser replaces the 33 cruiser since summer 2007.

Length overall	10,71 m
Length hull	10,45 m
Length waterline	9,20 m
Beam overall	3,60 m
Draught standard	approx. 1,90 m
Draught option	approx. 1,55 m
Unloaden weight	approx. 5.700 kg
Ballast	approx. 1.440 kg
Engine	Volvo-Penta D1-20, 13,3 kW/18 hp
Water tank	approx. 210 l
Fuel tank	approx. 150 l
Cabins / Berths	2 / 4
Mainsail & Genoa	approx. 59,2 sqm
Height of mast above waterline	approx. 14,84 m
Height in salon	approx. 1,87 m

Exterior

Hull

• Hull color white
• 2 hull windows (fixed)

Rudder/Keel

• Cast iron keel as deep keel
• Symmetrical rudder with fore balance
• Emergency tiller

Steering pedestral

• 1 steering pedestal with compass and steering wheel with leather
• Instrument console in steering pedestal

Deck

• Deck ventilator
• Side deck and coach roof with anti slip structure
• 4 aluminum cleats
• Coaming for sprayhood
• Genoa traveller, line adjustable
• Main sheet traveller, adjustable
• Pulpit, pushpit
• Guardrail
• Bow fitting with anchor roller

Bathing platform

• Bathing platfrom with teak
• Bathing platform electrical retractable
• Bathing ladder stainless steel (telescope)
• Cockpit-shower, cold and warm water (prepared)

Hatches and side windows

• 5 hatches to open
• 6 port lights to open

Cockpit

• Teak on cockpit floor and cockpit seats
• Cockpit table
• Box for gas bottles, self drained

Standing/running rigging

• Mainsail, coordinated for conventional rig
• Genoa, coordinated for standard fore sail reefing gear
• Conventional Sport rig

Winches

• 2 winch handles
• 2 halyard winches, self-tailing
• 2 genoa winches, self-tailing

Interior

Cabins

• 2 cabins
• Cabinet in foreship and aft cabin

Bathroom

• Pump-toilet with holding tank, disposal via seacock and deck

Salon

• Salon table, fixed
• Salon with settee
• Upholstery Uni turquoise / grey /creme / Dark blue
• Sideboards, shelves and cabinets
• Handholds (wood)
• Storage space with drawers and flaps

Navigation

• Chart table with instrument console
• Chart table seat

Pantry

• 2-flame gas cooker with oven
• Icebox with compressor
• Stainless steel sink
• 3 fire extinguisher
• Fire extinguisher blanket

Miscellaneous

Fresh water

• Fresh water tank with level indicator, 210 l
• Electrical pressurized water pump with filter

Bilgepumpe

• Manual bilge pump
• Electrical bilge pump

Engine

• Two circuit cooling with seawater filter
• Engine hour meter and rev meter
• Voltmeter, Fuel indicator

Electrical System

• Engine circuit 88 Ah, on board electrical system 135 Ah
• Main power supply with circuit breaker and control lamps
• AC-outlet package (1 per cabin and 2 in galley)
• Shore supply 230 V (1x 230 V AC-outlet on switch board)
• (shore supply 110 V for surcharge)
• 12 V outlet at switch board

Navigation

• Windex
• Navigation lamps, deck light

Exterior

Rudder/Keel

• Cast iron keel as shallow keel (1,57 m)
• Bow thruster SE 60, electric (only in combination with 2nd service battery)

Anchor

• Electrical windlass
• Plough anchor, zinc-coated
• Anchor chain, zinc-coated, Ø 8 mm, 50 meters
• Anchor chain, stainless steel, Ø 8 mm, 50 meters

Deck

• Teak on side deck and coach roof
• Rail opening on both sides
• 2 spring cleats, aluminium, midships
• 4 stainless steel cleats
• 2 spring cleats, stainless steel (only in combination with 4 stainless steel cleats)
• Life-saving collar with holding device and life line, installed at pushpit
• Life raft (in bag)
• LFS-safety package, life-safety system

Bathing platform

• Cockpit-shower warm water only in combination with warm water boiler 20 l

Cockpit

• Sprayhood
• Bimini (deck rigging)
• Bimini, large (rigging on pushpit)
• Camper cover
• Upholstery on seat thwarts in cockpit

Standing/running rigging

• Fully battened mainsail, with MDS-system and lazyjacks, reefing genoa
• High-tech sailset for mainsail-furling system; furling main, EMS-System, sandwich laminate, reefing genoa with e-foam, tri-radial, cut and surface optimized.
• High-tech sailset for battened main and genoa, cut and surface optimized, sandwich/laminate cloth; battened main incl. MDS & lazyjacks, bi-radial; reefing genoa with e-foam, tri-radial.
• Backstay adjuster, tackle
• Spinnaker gear complete with spinnaker boom and holding device; downhaul with separate chain plate; Excenter cleats for halyard and topping lift, stopper for downhauls, leading blocks at mast and rail stanchions, leading blocks.
• German mainsheet-system without winches
• Rodkick with gas pressurized spring
• Gennaker boom
• Mainsail furling system

Winches

• 2 x Spi-/ mainsheet-winches, 2-gear, self-tailing

Interior

Bathroom

• Shower in head

Salon

• Deck ventilator, stainless steel

Pantry

• Microwave

Miscellaneous

• Steel cradle for oversea transport
• First aid kit "Coastal"
• Hot air heating, 3,5 KW, fuelling via engine fuel tank

Water supply

• Warm water boiler 20 l via engine-cooling circuit and via 230 V shore supply

Engine (additional charge to basic engine)

• Volvo-Penta D1-30, 20,1 kW / 27,3 hp, Saildrive
• Folding propeller, 3-blade

Electrical system

• 2nd additional battery, 135 Ah
• Shore supply 110 V (1x 110 V AC-outlet on switch board)
• Battery charger, 45 A (3-channel)

Multimedia

• TV 19" in Salon with DVD
• TV cabling, incl. antenna with AC-outlets
• Radio with CD-/MP3-Player with 2 speakers in salon

Navigation

• VHF-cabling, incl. antenna, installed in mast to chart table
• Raymarine Tridata ST 60 Plus (log, echo sounder and temp), per unit
• Autopilot, Raymarine ST 6002
• Electr. wind gauge, Raymarine
• Chart plotter, Raymarine C 80 with GPS
• Chart plotter, Raymarine E 80 with GPS, for chart table only

Performance

• German mainsheet-system without winches
• Rodkick with gas pressurized spring
• High-tech sailset for battened main and genoa, cut and surface optimized, sandwich/laminate cloth; battened main incl. MDS & lazyjacks, bi-radial; reefing genoa tri-radial
• Backstay adjuster, tackle
• Spinnaker gear complete with spinnaker boom and holding device; Downhaul with separate chain plate. Excenter cleats for halyard and topping lift, stopper for downhauls, leading blocks at mast and rail stanchions, leading blocks, spi-lift system
• Gennaker boom
• Raymarine Tridata ST 60 Plus (log, echo sounder and temp)
• Folding propeller, 3-blade

Family

• 2 spring cleats, aluminium, midships
• German mainsheet-system (without winches)
• Sprayhood
• Bimini (deck rigging)
• Rodkick with gas pressurized spring
• Mainsail-furling system
• Battery charger, 45 A (3-channel)
• 2nd additional battery, 135 Ah
• Microwave
• Warm water boiler 20l via engine-cooling circuit and via 230V shore supply
• Raymarine Tridata ST 60 Plus (log, echo sounder and temp)

Family - north (Equipment analog to Family)

• without Bimini and Sprayhood

Holiday

• 2 spring cleats, aluminium, midships
• Sprayhood
• Bimini (deck rigging)
• Rodkick with gas pressurized spring
• Battery charger, 45 A (3-channel)
• VHF-cabling, incl. antenna, installed in mast to chart table
• Shower in head
• Warm water boiler 20l via engine-cooling circuit and via 230V shore supply
• Raymarine Tridata ST 60 Plus (log, echo sounder and temp)
• Auto pilot, Raymarine ST 6002
• Electr. wind gauge, Raymarine

Comfort

• Teak on side deck and coach roof
• Rail opening on both sides
• 4 stainless steel cleats
• 2 stainless steel spring cleats
• German mainsheet-system (without winches)
• Sprayhood
• Bimini (deck rigging)
• Rodkick with gas pressurized spring
• Mainsail-furling system
• Battery charger, 45 A (3-channel)
• 2nd additional battery,, 135 Ah
• Microwave
• Warm water boiler 20l via engine-cooling circuit and via 230V shore supply
• Raymarine Tridata ST 60 Plus (log, echo sounder and temp)
• Electr. wind gauge, Raymarine



Function package (bundle)

Ancoring

• Electrical anchor winch
• Plough anchor, zinc-coated
• Anchor chain, zinc-coated, Ø 8 mm, 50 meters

Multimedia

• TV 19" in salon with DVD
• TV cabling incl. antenna and AC-outlets
• Radio with CD-/MP3-Player with 2 speakers in salon

Safety

• Life-saving collar with holding device and life line, installed at pushpit
• LFS-safety package, life-safety system
• Life raft (in bag)
• First aid kit coastal

Navigation I

• VHF-cabling, incl. antenna, installed in mast to chart table
• Raymarine Tridata ST 60 Plus (log, echo sounder and temp)
• Auto pilot, Raymarine ST 6002
• Electr. wind gauge, Raymarine

Navigation II

• VHF-cabling, incl. antenna, installed in mast to chart table
• Raymarine Tridata ST 60 Plus (log, echo sounder and temp)
• Auto pilot, Raymarine ST 6002
• Electr. wind gauge, Raymarine
• Chart plotter, Raymarine C 80 with GPS (chart table)
